Flag: Liberia

Built: 2008

Yard: Damen Shipyards Grinches, Netherlands

Class: BV + Hull. Mach Tug Unrestricted Navigation

LOA 22.57 metres

Beam: 7.84 metres

Depth: 3.78 meters

Draft: 3.40 metres on SSW

GT / NT: 140 / 42



Accommodation

Accommodation: 8 persons

Crew Complement: 4 persons



Propulsion / Auxiliary Engines

Main Engines: 2 x Caterpillar 3512B TA/B, 1014 KW at 1600 RPM

2 x REINTJESS / WAF 665L Gear Box.

2 x fixed pitch propeller with kort nozzle.

Auxiliaries: 2 x Caterpillar C 4.4 t with Leroy Somer Generator, 56.4 KW at 1500 RPM

Bunkers / fuel in use: MGO, ISO 8217:1996 - DMA



Speed and Consumption:

Idle (free running)

Daily MGO Consumption
	Engine (RPM)	Speed (knots)	Main Engine (MT)	Generators (MT)	Total (MT)
Max Power	1600	12.0	10.0	0.4	10.5
Cont. rate	1400	11.2	7.0	0.4	7.4
Eco speed	1100	10.5	3.5	0.4	3.9
Slow	900	8.0	1.9	0.4	2.3



Note: Speed and consumption pending the towing object.



Tank Capacity

Bunker Tank Capacity: 36.8 CBM

Fresh Water Capacity: 8.60 CBM

Bollard Pull: 38.8 Tonnes (average), 39.3 Tonnes (maximum)



Navigational Equipment

Radar: 2 Furuno FR-8252 and FR-8082

GPS Navigator: 1 Furuno GP - 150

Gyros Interface:  1 SIMRAD G-151

Auto Pilot: 1 SIMRAD AP-50



Communication Equipment

VHF 1 Sailor RT 2048 + DSC

VHF 2 Sailor RT 2048 + DSC

Radio Furuno SSB FS-1570

NAVTEX Furuno NX-700



Towing Equipment

Towing Hook - SWL 450 kN

Towing winch on aft deck with a spooling device. Brake holding force 100 ton in 1^st layer

Towing wire - 500 metre with diameter 44mm fitted on towing winch drum equipped with wire socket MBL 170 MT
