Our vessels are built for various fishing applications including bottom trawling, purse seining, long lining, mining, squid fishing and research, and many vessels are custom built to satisfy the customer’s every need. Vessels are designed with a large hold capacity, yet still maintain spacious engine room and accommodation areas. Many of the vessels are built to include more than one application to allow for products to be processed at sea. The material is also so versatile that a range of sizes are available from 33 feet to 100 feet based on existing moulds.

Length overall: 13.85m
Length between perpendiculars: 12.20m
Beam: 5m
Draft: 2m
Gross tonnage: 24.90 t
Hold: 32 cub m
Fuel capacity: 5 000 liters
Fresh water capacity: 1000 liters
Crew: 16 men
Safety equipment for: 16 men


HULL, DECK, BULKHEADS ETC
Hull, deck, bulkheads, gunwhale, wheelhouse and watertanks in GRP
Diesel tanks in GRP.
Insulation
Hold insulation:100 mm
Bulkheads: 150 mm

ENGINE & PROPULSION

Main engine: Doosan 180HP (Heat exchange)
Heavy duty Dong-I gearbox
65mm 316 Stainless Steel shaft
Stern gear in manganese bronze
Propeller 4 blade
Rudder & Stuffing box


INSTALLATION OF THE FOLLOWING

Main engine and stern gear
Exhaust system for main engine in stainless steel
Controls for speed and gearbox
Plumbing and filtration for fuel system for main and gen set
Piping for cooling system
Fully hydraulic system with autopilot solonoid
Three seacocks bronze
Fresh and seawater pump system
Electrical system - 24V
Gas burner 2 plate


SAFETY EQUIPMENT:  CAT A1(A)
As per South African Maritime Safety Authority Spefcifications

ELECTRONICS
Electronics Owner to specify

OPTIONAL EQUIPMENT

Hold ponds with cleats and varnished (Rubol)

Deck laaitjies 8 per side
12mm ply 3layers glassed over and flocoated
Partition in hold for blast freezer
Aft storage platform in st.steel
Fit refrigeration equipment with condenser piping
Manufacture galv racking for 2 tons
Installation of one gen set
Gen set 75KVA Lovol
Electrical system 220/380 V
Standby system for radios
Electric winch
17KW Bitzer screw compressor freezing system
3KW holding room compressor system

EXCLUSIONS
Fuel & Oil
Insurance - Vessel covered by Builder until after sea triales.


CONDITIONS OF SALE
Quoted price is based on current factory prices, surcharges and duties.
Any adjustment to these will be for the customers account.
Payment
a.  20% deposit on order
b. 30% down payment when construction commence.
c.  30% down payment when hull, gunwhale and super structure are completed.
d.  Balance payable after sea trials at delivery.
Construction of vessel will only commence once first down payment has been received.
Fuel and oil excluded.
All quoted prices in SA Rands excluding VAT.
Vessel constructed to Lloyds specifications and approved by South African Maritime
Safety Authority.
