NEW BUILD - 45m LCT

Listing ID - 413175
Description	NEW BUILD - 45m LCT
Date Launched	Delivery 12 months
Length	45.00m
Beam	10.00m
Draft	2.20m (2.60m max draft)
Location	ex Shipyard, Malaysia
Broker	Peter Cookson peter.cookson@seaboatsbrokers.com +61 429 543 180
Price	POA
View As PDF

Classification: ABS/BV/LR +A1 +AMS Unrestricted Services

Port of Registry & Flag: Malaysia / others

MAIN DIMENSION

Length Overall: 45.00m

Length WL: 42.12m

Beam: 10.00m

Depth: 3.60m

Designed Draft: 2.20m (2.60m max draft)

Gross Tonnage: 490 approx

Dead weight: 300T approx

TANK AND LOADING CAPACITY (APPROX.):

DOUBLE BOTTOM AND SKIN

Fresh Water: 200m³*

Cargo Fuel 350m³*

Ship fuel: 32m³

Slop tank: 65m³

Ballast / Drill Water: 65m³

Deck Area: 200m²* approx.

Deck Cargo: 300 Tonnes approx.

Deck Strength: 5 MT/m2

PERFORMANCE

Speed: 12 knots

Endurance: 20 Days

STRUCTURE, DECK MACHINERY AND FITTINGS

Ramp door: Hydraulic lifting

Bow Anchor: 2 x 660kg Stockless anchor with 10 shackles anchor chain

Windlass: Electro Hyd. Twin Gypsy

Deck Covering: Wooden sheathing

Side gate: With universal rollers to allow reeling on hoses from the ramp to the side

Fender: Half pipe

Reefer Connection: 6 Nos

CARGO HANDLING EQUIPMENT

Fuel Cargo pump with meters: 1 x 80m³/hr at 60m head

FW cargo pump: 1 x 60m @ 40m head

Other pumps: As per class

MACHINERY

Main Engines: 2 x 600 BHP @ 1800 rpm heat exchange cool ed, spark arrestors

Gearbox: Twindisc 4.86

Generator: 2 x 80KW 415/3/50

Bow Thruster: Tunnel thruster, Min 3 ton

Propulsion (shafting): Waterlub stern tube, fixed pitch with kort nozzle

Steering gear: Electro – hydraulic

NAVIGATION AND COMMUNICATION

Communication equipments complied WITH FLAG

Intended: A3

SAFETY AND FIREFIGHTING EQUIPMENT

In compliance with SOLAS, & Class requirement and requirement of Flag administration

POLLUTION CONTROL

Comply to Flag state regulation

MARPOL 1, III, IV, V, VI

ACCOMMODATIONS & UTILITY

Comply to MLC T3

Fully Air conditioned: Total 12 Berth

Chiller and freezer: 1 unit each

Galley Facility: All electric cooking

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
