Listing ID - 1255403 | |
|---|---|
| Description | 26.5m Purse Seiner |
| Date Launched | New Build |
| Length | 26.5m (86ft 11in) |
| Beam | 7.45m (24ft 5in) |
| Draft | 4m (13ft) |
| Location | South Africa |
| Broker | Geoff Fraser geoff.fraser@seaboats.net +64 21 61 222 5 |
| Price | POA |
| View As PDF | |
These vessels are built for various fishing applications including bottom trawling, purse seining, long lining, mining, squid fishing and research, and many vessels are custom built to satisfy the customer’s every need. Vessels are designed with a large hold capacity, yet still maintain spacious engine room and accommodation areas. Many of the vessels are built to include more than one application to allow for products to be processed at sea. The material is also so versatile that a range of sizes are available from 33 feet to 100 feet based on existing molds.
Specifications
Vessel Condition: New Build
Vessel Type: Purse Seiner
Builder: Tallie Marine
Model: Purse Seiner
Nominal Length: 26.50m
Length Over all: 26.50m
Beam: 7.45m
Maximum Draft: 4m
Hull Material: Glass Fibre
Hull Type: Semi Displacement
Displacement: 210 metric tons
Fuel Capacity: 22000 Litres
Water Capacity: 3000 Litres
Holding Tank Capacity: 300 Cubic Metres
Heads: 12
No. of Engines: 1
Engine Model: MTU 8V400
Engine Power: 1000HP
Fuel Type: Diesel
Drive Type: Stern Drive
Cruising Speed: 10 knots
Maximum Speed: 11 knots
Engine(s)
Main engine -MTU 8V400 with gearbox WAF542L 3.99-1
130mm 316 Stainless steel shaft. (Duplex s. steel)
130mm Stern gear complete
Four blade propeller
Rudder stock and rudder
1 X Doosan LO66TI 120KVA
Construction
Hull, deck, bulkheads, whale deck, halve shelter deck,
and super structure.
Water and diesel tanks in GRP.
Six separate holds. (Two bulkheads fore/aft & one diagonally)
Insulation
Perforated plating on centre partition
Equipment
Main engine and stern gear
Two auxiliary engine
Exhaust systems - Outside engine room - stainless steel
3.1 Main engine
3.2 One aux engines
Keel cooler for main engine and generator set
Plumbing and filtration for fuel systems
Piping for cooling system for main engine and gen sets
Fully hydraulic steering system
3 Seacocks in stainless steel 90mm
Fresh water system
Electrical system 24/220/380V transformer included
Sea water system for bilges, holds, deck wash and fire main
Three x 60,000 lph bronze pumps
Stern and bow thruster Installation only
Standby system for radios
Supply and fit one x sonar tanks
Supply and fit bull wark roller system
Fit deck equipment
including fish Shute and dewatering overboard
Supply and fit cooler for hydraulic system
Supply and fit deck equipment as per PETEC
