Built: 2015, United Kingdom

Hull material: Aluminium

Flag: United Kingdom

Class Society and Notation: MCA CAT 2



Length Overall: 24m

Breadth: 4.3m

Depth: 6.3m

Draft: 0.80m

NT: 21 tons

GT: 28 tons

DWT: 19 tons



Total power output: 1200 bhp

Main Engines: 2x Doosan 4V222TIL

Main Propulsion System: Water jet

Speed maximum: 50 knots

Speed cruising: 40 knots



Latest dry dock Jan 2022. Jets rebuilt and impellors reconditioned. Extended fuel tanks installed to give an extra ten hours range at 33 knots.



Running hours: less than 1500hrs on all machinery.



Currently within code and ready to work as CAT 2 with a CAT 1 coding immediately available with the addition of an appropriate medical kit, stability books all completed for CAT 1 work and coding.



It can be delivered anywhere worldwide as required (with delivery cost to be considered).



LWL length at water line 22.4m

Depth incl mast

Draft 0.8m coash house roof

Displacement (light): 20.5 tonnes

Displacement (heavy): 28.0 tonnes

Propulsion: 2 N° Castaldi water jet TD490 HC

Fresh water: 250 L, Black water 250 L

Fuel 2500 L total (6 tanks)

Fuel consumption circa 380 L/hr at full power absorption



The vessel can comfortably maintain high operating speeds in wave heights of 2 meters. At these speeds the vessel is very fuel efficient and with the benefit of a gyro-stabiliser the vessel can loiter at sea without the vessel "rolling" uncomfortably. In addition to crew transfer, this vessel could work in many other roles including marine ambulance, patrol, safety etc. It has been built as a demonstration proof of concept vessel and, either the prototype could be sold or parties can have vessels built specifically to their end-user specification.



The design intent is that up to 12 passengers and a max 3 crew can travel safely, comfortably and with minimal motion sickness influence at up to 40 knots in seas of up to 2m.



The vessel can equally well be used as a fast response vessel for both technicians and / or equipment.



One of the design briefs was to consider that the vessel may remain at sea, working from an accommodation station where it may be craned on and off the platform, (fully laden), or be entering / exiting a floating dock system.
