NEW BUILD - 20m Crew Boat

Listing ID - 5774
Description	NEW BUILD - 20m Crew Boat
Date Launched	Built to Order
Length	19.98m (65ft 6in)
Beam	5.6m (18ft 4in)
Draft	1.6m (5ft 2in)
Note	Main Engine: 2x Weichai
Location	UAE
Broker	Craig McKay craig.mckay@seaboatsbrokers.com +61 412 295 595
Price	USD 1,510,500
View As PDF

GENERAL VESSEL SPECIFICATIONS

Type: Crew Boat (IACS Class)

Overall Length: 19.98m

Breadth: 05.60 m

Depth: 02.60 m

Draft (Max): 01.60 m

Freeboard: 01.00 m

Speed: 15 knots

Passenger Capacity: 18 person

Crew: 6 person

PLATING THICKNESS & CAPACITY

Sides, Bulkheads: 6mm (5083 Aluminium plates)

Keel: 8mm (5083 Aluminium plates)

Deck: 6mm (5083 Aluminium plates)

Cabin: 6mm (5083 Aluminium plates)

Transom: 8mm (5083 Aluminium plates)

Transverse Sections: 6mm (5083 Aluminium plates)

PROPULSION

Main Engine: 2x Weichai, WP12C500-18, kW 368, rpm 1800

Reduction Gearbox: 2x Advance, Model: HC300, Ratio 2.23:1

Stern Gear Design: 1x Design of Propeller, Rudder and Shafting arrangement

Laiden Cruise Speed: 15 knots

Stern Gear:

2x Propeller - NIAL-Cu3, 36" Dia, 4 Blades

Propeller Shaft Assembly, Dia 70 mm, F51 Duplex Steel

Stern Tube Assembly, Dia 152.4 mm x 3000 mm Long

P Bkt, NIAL-CU3, 40 x 250 x 1200 mm

Stern Tube Seals & Bearings: 2x Stern Tube Seal, Stern Tube Bearing and P Bkt Bearings

Engine throttle control system: 1x Kings Control KC 200 – H200 Dual Type Fixed Engine Control Head with A200 Mechanical Actuators

Steering Gear: Electro Hydraulic

Rudder: 2x Single Blade Spade Rudder, NIAL-CU3, 520 x 900mm

POWER

Diesel Generator: 2x Weichai, WP2.3D40E200 Engine with Shanghai Stamford CCFJ30J-H Alternator, Sea water cooled, 30 kW, 415 V, 3 Ph, 50 Hz

MSB: 1x Switch board panel with Voltmeter, kW meter, Frequency meter, Ammeter, Insulation meter, Breakers and accessories

Distribution Panels: 12x Start / Stop local control panels for:

* FO transfer pump x 1

* Bilge, fire and ballast pumps x 2

* FW hydrophore skid x 1

* STP x 1

* AC Units x 3

* ER blowers x 4

PUMPS

Fuel Oil Transfer Pump with Motor: 1x 5 m3/hr @ 2 bar, Gear / Screw Type

Fire, Bilge & Ballast Pump with Motor: 2x 25 m3/hr @ 3 bar, Centrifugal Type with Self-Priming Unit

Lube Oil Hand Pump: 1x 2 m3/hr @ 2 bar, Semi-Rotary Type

Sewage Pump with Motor: 1x 5 m3/hr @ 4 bar, Centrifugal Type

Oily Water Hand Pump: 1x 4 m3/hr @ 2 bar, Semi-Rotary Type

Fresh Water Pump with Motor: 1x 3 m3/hr @ 5 bar, Centrifugal Type

Freshwater Hydrophore Skid: 1x Pump Capacity: 1 m3/hr @ 2 bar x 2 Nos, Hydrophore Tank: 100L, With Air Compressor

Fresh Water Cargo Tank Pump: 1x 5 m³/hr at 5 bar, Centrifugal Type

Emergency Potable Fire Pump: 1x 25 m3/hr @ 2.5 bar, Portable Centrifugal Type with Self Priming Unit

LSA & FFA

Multiple loose items: Set, As per Fire control & Safety plan

Fire detection and alarm System: 1 Set, As per Fire control & Safety plan

Aerosol Fire Suppression System: 1 Set, As per Gross volume of E/R

Deck Equipment

Anchor, Anchor Chain and Winch: 1x Anchor weight: 48 Kgs, Studless, Chain Dia: 8mm, Chain lengths: 82.5m, Proof load: 24kN, Breaking load: 48kN, Windlass continuous duty pull: 3.06kN

Mooring Ropes: 7x Design brake force: 78.75T, Dia:18mm, Breaking strength: 85.7T

Tyre Fenders: 32x Dia 700mm

Navigation & Communication

Radar: 1x Onwa, KR-1008, 32NM

GPS: 1x Onwa, KP-27

MFHF Complete Set: 1x CETC WT-6000 MFHF SSB Radio

PA System: 1x Intercom for Bridge and Cabins with Amplifier and Horn Speaker

Air Horn: 1x Marco 24V 10Amp Electric Air Horn System

Magnetic Compass: 1x Iluminated YQ-50F

Navigation Lights: 1x Navigation Light Panel (8CH)

AIS: 1x EM Track A 200 Class A

Portable VHF: 1x Marinelite Class A DSC VHF, Model VHF9000

EPIRB: 1x AIS EPIRB, Model-VEP8A

SART: 1x AIS SART S9000

Navtex Receiver: 1x CETC ME1701

Battery Charger: Victron TG24/30A Battery Charger

Battery: 2x 12V 200AH Battery for GMDSS equipment

Deck Outfitting

Doors: 3, As per Design

Windows: 11, As per Design

Scuttles: As per Design

Hatches: As per Design

Bollard: As per Design

Fair lead / Chocks: As per Design

Miscellaneous Equipment

STP: 1x Marine Sewage Treatment Plant, For 10 persons, Model: HBNA-10, Supply: 380V 50Hz 3Phase

ER Fresh Air and Exhaust Blowers: 4x Exhaust fan, 9000 CMH, 150Pa, 1.5kW, 1440rpm, 2 sets

Air Vents: As per design

Batteries: As per design

AC Systems: 1 Lot, Split AC for Passenger area x 1, Split AC for Wheelhouse x , VRF unit with 1 outdoor and 3 indoor units for Crew accommodation

Pilot Chair: 1x Luxury, Non-reclining

Passenger Chairs: 19 Luxury, non-reclining

Interior work: 1 Lot: Passenger Area + Wheelhouse+ Crew Accommodation area + Pantry

Toilet: Bulkhead panelling, Flooring, Ceiling, Lighting, Sanitary ware, Plumbing, Bedding, Furniture, Fridge, Hotplate etc.

Insulation Work: 1 Lot: 50mm wool insulation supply and fixing in Passenger Area, Wheelhouse, Crew Accommodation area, Pantry, Toilet

Paints

Paints: 1 Lot, International paint scheme for 5 years service life

Surface preparation and Paint application: 1 Lot, Full masking and protection of

surrounding areas, full surface preparation by sanding & cleaning. Apply one primer coat, one anti-

corrosive cost and one final coat. Wash down of all painted area.

Pipe & Fittings

CS Galvanized: 1 Lot, As per design

Aluminium: 1 Lot, As per design

Valves and Others

Valves and Instruments: 1 Lot, As per design

Anodes: Hull anodes: 1 Lot, As per design

Engine Accessories: Wet exhaust system: 4 As per design

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
