79.8m 3500t Bulk Carrier for Sale

Listing ID - 3950
Description	3500t Bulk Carrier for Sale
Date Launched	2021
Length	79.80m (261ft 9in)
Beam	14m (45ft 11in)
Draft	5.30m (17ft 4in)
Note	4586.300t
Location	China
Broker	Ivan Colaco ivan.colaco@seaboatsbrokers.com +61 401 695 814
Price	USD 2.5 million
View As PDF

Built: June, 2021

Hull Material: Steel

Class Society: China Classification Society (CCS)

LOA: 79.80m

LWL: 76.80m

LPP: 75m

Beam: 14m

Depth: 6.50m

Draft: 5.30m

Displacement: 4586.300t

Light Displacement: 1467.98t

Height: 0.18m

Gross Tonnage: 2127

Net Tonnage: 1189

Load Capacity: 3076 t

Host Model: G6020ZCA ltower

Calibration Power: 1800 HP

Speed: 13-15 knots

Navigation Speed: 15 knots per hour

Service Area: Coastal Shipping Area

Number of Crew: 12 people

Fuel Tank Capacity: Total 200t actual

Oil Tank Capacity: 200 ton per day

Crew: 12 persons, min 10

Deck Height

Main deck to Forecastle Deck: 1.80m

Main Deck to Poop Deck: 2.60m

Poop Deck to Flying Deck: 2.50m

Flying Deck to Lo Path Deck: 2.30m

Rib Distance

Whole Ship: 600mm

Double Bottom Height

Double Bottom Height: 900mm

Main Engine

Host: 1 tower

Model: G6300ZCA

Rated Power: 1800hp

Gearbox: 1 tower

Model: MG45.49

Reduction Ratio: 3.5:1

Cabin Capacity

Cargo Hold Capacity

Serial Number: 1

Cabin Name: Cargo Hold

Rib: #25~#107

Net Volume (m3): 3889.03

Fresh Water Tank

Serial Number: 1

Cabin Name: Fresh water tank (left and right)

Rib: #22~#39

Net Volume (m3): 25.87×2

Serial Number: 2

Cabin Name: Daily water tank (left and right)

Rib: #12~#14

Net Volume (m3): 2.16×2

Fuel Tank Capacity

Serial Number: 1

Cabin Name: NO.1Oil tank (left and right)

Rib: #4〜#7

Net Volume (m3): 18.69×2

Serial Number: 2

Cabin Name: NO.2Oil tank (left and right)

Rib: tail~#4

Net Volume (m3): 33.62×2

Serial Number: 3

Cabin Name: Daily oil tank (left and right)

Rib: #4〜#7

Net Volume (m3): 14.91×2

Ballast Water Tank Capacity

Serial Number: 1

Cabin Name: First ballast tank

Rib: #120~head

Net Volume (m3): 57.31

Serial Number: 2

Cabin Name: NO.1Ballast tank (left and right)

Rib: # 116〜#120

Net Volume (m3): 4.19×2

Serial Number: 3

Cabin Name: NO.2Ballast tank (left and right)

Rib: #107〜#116

Net Volume (m3): 17.12×2

Serial Number: 4

Cabin Name: NO.3Ballast tank (left and right)

Rib: #93〜#107

Net Volume (m3): 42.78×2

Serial Number: 5

Cabin Name: NO.4Ballast tank (left and right)

Rib: #75〜#93

Net Volume (m3): 63.32×2

Serial Number: 6

Cabin Name: NO.5Ballast tank (left and right)

Rib: #57〜#75

Net Volume (m3): 63.34×2

Serial Number: 7

Cabin Name: NO.6Ballast tank (left and right)

Rib: #39〜#57

Net Volume (m3): 61.81×2

Serial Number: 8

Cabin Name: NO.7Ballast tank (left and right)

Rib: # twenty-two〜#39

Net Volume (m3): 39.77×2

Rudder

Rudder Blade Area: 7.40m2

Number of Rudders: 1

Aspect Ratio λ: 1.52

Balance Ratio β: 0.26

Area Ratio μ: 1.86

Lifesaving Equipment

15 Man Self-supporting Formal Life Raft: 20 only

Rope Ladder: 2 sets

Life Jacket (with life jacket light): 15 pcs

Pilot Ladder: 1 set

Life Jacket: 12pcs

Rocket Parachute Signal: 12 pcs

Lifebuoy with Self-igniting Light: 40 only

Lifebuoy With Lifeline: 40 only

Self-igniting Light Lifebuoy with Smoke Signal: 20 only

Emergency Escape Breathing Apparatus: 8 tools

Lifesaving Rope Thrower: 4 tools

Radar Transponder: 20 only

Emergency Radio Beacon: 1 set

Portable Cordless Phone: 30 only

Fire Equipment Configuration

Fire Hydrant: 80 only

9LPortable Foam Fire Extinguisher: 90 only

5KgPortable Dry Powder Fire Extinguisher: 100 only

5KgPortable CO2 Fire Extinguisher: 20 only

20LPortable Foam Gun: 1 only

International Shore Connection: 20 only

Yellow Sand Box: 40 only

Fire Water Cage Belt and Box: 8 sets

45LTrolley Foam Fire Extinguisher: 1 only

Firefighter Equipment: 2 sets

Peace Axe: 40 only

Fire Isolation Valve: 1 only

Iron Hook, Iron Drill: 1 set

Fire Bucket: 60 only

Navigation Equipment

Standard Magnetic Compass: 1set

Radar: 1set

Automatic Identification System (AIS): 1set

Rudder Angle Indicator: 1Only

Sounding Hammer: 1Only

Rain and Snow Remover: 20 only

Steering Magnetic Compass: 1 set

Echo Sounder: 1 set

Satellite Navigator: 1 tower

Electronic Chart System: 1 set

Tail Shaft Tachometer: 1 only

Radio Equipment

Medium and High Frequency Radio: 1set

VHF Telephone: 1set

Navotas Receiver: 1set

Satellite Emergency Radio Position Indicating Beacons: 1tower

Radar Transponder: 2 individuals

Two-way VHF Radiotelephone for Survival Craft: 3 individuals

Other Devices

Bilge, Fire, General Pump

Emergency fire pump

Servo hydraulic unit

Engine room ventilation unit

Side push cabin, emergency power generation Room ventilation unit

Fresh water pressure tank

Domestic sewage treatment device

Daily bilge pump

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
