Registry/Delivery: Australia / December 2012

Official Number: 860900

Call Sign: VJN4416

IMO Number: 9648219

Length: 28m (91ft 10in)

Breadth: 11m (36ft)

Depth Moulded: 3.25m (10ft 7in)

Designed draft: 2.275m (7ft 5in)

Classification: ABS +A1 (E), Towing Vessel, +AMS

GRT / NRT: 247/74 Tons

FO/FW Tank: 141.2m³ / 53.70m³

Total Deck Space: Approx. 10 knots

Bollard Pull: 19 tons



ENGINE ROOM

Fuel Oil Transfer Pump – 25m³/hr

Sewage treatment plant with holding tank

Blower fan – 2 x 19” for Engine Room

Fitted with SOLAS / Class Approved CO² Fire Suppression System



MAIN ENGINES / GENERATORS

Main Engine: 2 x Caterpillar C32 ACERT – 750bhp @ 1800rpm

Gear Box: Twin disc MGX5222 Ratio 4.59:1

Generator: 2 x Caterpillar C6.6 ACERT 125ekW @ 1500rpm/50Hz/415V/p.f.0.8 (IMOT1)

Propeller: 2 x Fixed Pitch 4 Blade (1400mm) with Kort Nozzles



DECK MACHINERY

2 x Anchor Windlass: Electrical hydraulic anchor windlass having capacity 2.0 tons @ 10m/min Single gypsy suitable for 19mm dia. Stud link chain, 2 x 300kg Stockless Anchors

2 x Crane: FASSI F1100RAFM 2.24 He-Dynamic Knuckle Boom Crane (Bow & Aft), Max 25 ton @ 3.5m, Min 8 ton @ 11.25m; Individual Hand-held Remote Control

Fork Towing Pin: Hydraulic Self Lifting FTP 35T WLL; Local & Remote Control

Towing Hook: Towing Hook 30 ton WLL with hydraulic emergency release

Towing Winch: 1 x ME S’pore 25 ton Single Drum Winch with 50 ton Brake holding capacity ; Local,  Remote & Pendant Control

Towing Wire:  32mm dia. x 400m (6x36) IWRC EEIPS RHRL Galvanized Wire Rope

A-Frame/Rollers:  Class Approved Anchor Handling A-Frame

Rollers: Bow & Stern Rollers Fitted

Controls: Wheelhouse & Steering Gear Control – Fore & Aft



NAVIGATION / COMMUNICATION EQUIPMENT

Radar:  Furuno FR 8062

VHF: Furuno Make

GMDSS Inmarsat C Sys.: Furuno A1+A2+A3

SSB Radio: Furuno Make

GPS Navigator: Furuno GP-150

GPS Chart Plotter: Lowrance HDS-10

Magnetic Compass:  DAIKO SR-150PK

Speed Log: Furuno Make

Universal AIS: Furuno FA-150

Echo Sounder: Furuno FE-700

Navtex Receiver: Furuno NX-700

PA system:  Huayuan

Intercom: Huayuan

Wind Speedometer: Furuno FI-50

Facsimile Receiver: Furuno Fax-400



ACCOMMODATION / LIVE-SAVING & FIRE FIGHTING EQUIPMENT

Accommodation: 1 x 1 man (Captain); 1 x 2 men;  2 x 4 men

Life rafts:  2 x 15 men SOLAS (Bridge & Main Deck)

EPIRB:  McMurdo E5 Smartfind 406

SART:  McMurdo S4 Rescue SART

Pyrotechnics, Life-buoys, Various Fire Extinguishers. Co2 Suppression System, Fireman’s Outfit & BA Set. Fitted to Statutory Req. of S’pore Non-convention Vessels, SOLAS & Australian regulations
