Hull: 168

Vessel Type: Offshore Supply Vessel

Year Built: 1998

Year Converted/Modified: 2007



Dimensions: 272 ft. X 56 ft. X 18.9 ft. (82.91 m X 17.07 m X 5.72 m)

Draft (Lightship): 7 ft. 3 in. (2.21 m)

Draft (Loadline): 15.19 ft. (4.63 m)

Clear Deck: 185.5 ft. x 46.5 ft. (56.54 m X 14.17 m)

Cargo Deck Area: 8,625 sq. ft. (801.17 sq. m)

Deck Cargo Capacity: 1,900 LT (1,930.49 MT)

Deadweight Tonnage: 3,045 LT (3,093.86 MT)



Fuel Oil: 214,310.7 gals. (811.25 cu. m)

Ballast: 333,401 gals. (1,262.06 cu. m)

Potable Water: 36,620 gals. (138.62 cu. m)

Dry Bulk: 6,828 cu. ft. @ 80 psi (193.37 cu. m @ 5.5 bars)

Liquid Mud: 13,179.14 barrels (2,095.32 cu. m)



Main Engines: Two (2) CAT 3516 Diesels, 3,420 bhp

Bow Thrusters: One (1) 1,200 hp Dropdown

Bow Thrusters: One (1) 850 hp CP Tunnel

Stern Thrusters: Two (2) 1350 HRV Ulstein Azimuthing

Speed: 14.2 knots

Generators: Three (3) x 300 kW

Generators: One (1) x 105 kW



Tuggers: Two (2) x 4 Tons

Ship Motion: Two (2) Passive Type Anti-Roll Tanks

Ship Motion: Bilge Keels

Positioning: DP 2

Deck Crane: One (1) x 3,100 lbs. Capacity

Firefighting: One (1) 5,280 GPM Monitor



Life Rafts: Four (4) x 20-Man Inflatable Life Rafts

Life Rafts: One (1) x 10-Man Inflatable Life Raft

Other gear as required by authorities



Electronics Package: Furuno FR-1510 Radar (Port Side), Furuno RDP-150 Radar (Starboard Side), Sea 7156 VHF/FM Radiotelephone (Port Side), Two (2) Standard Horizon VHF/FM Radiotelephones, Two (2) Seacall 7100 JFHF/FM DSC Controllers, Sea 330 HF/SSB Radiotelephone, Seacall 7000 MF/HF DSC Controller, Necode DSC Controller, Sailor R501 2182kHz Watch keeping Receiver, JRC NDZ-127C Data Terminal (Mobile Earth Station), Inmarsat-C Seator Telex, One (1) Marine Technologies DPS-2 System, Kongsberg Simrad Autopilot OT, Furuno GPS/WAAS Navigator GP-32, Furuno FCV-600L Colour Video Sounder, Marine Technologies VSAT Phone, Furuno AIS



ABS: Maltese Cross A1 (Hull)

ABS: Maltese Cross AMS (Machinery)

ABS: Loadline (Unrestricted Ocean Service)

ABS: Circle E (Equipment)

USCG: Subchapter L (OSV)

SOLAS: 1994



Accommodations: 30
