Hull: 217

Vessel Type: Offshore Supply Vessel

Year Built: 2002

Shipyard: North American Fabricators



Dimensions: 260 ft. X 56 ft. X 21 ft. (79.25 m X 17.07 m X 6.40 m)

Draft (Lightship): 6 ft. 6 in. (1.98 m)

Draft (Loadline): 18 ft. (5.49 m)

Freeboard (Loadline): 3 ft. (0.91 m)

Freeboard (Lightship): 14 ft. 6 in. (4.42 m)

Clear Deck: 185 ft. x 46 ft. 6 in. (56.39 m x 14.17 m)

Cargo Deck Area: 8,602.5 sq. ft. (799.2 sq. m)

Deadweight Tonnage: 3,450 LT (3,505.36 MT)



Fuel Oil: 263,521 gals. (997.54 cu. m)

Ballast: 204,841 gals. (775.41 cu. m)

Potable Water: 24,014 gals. (90.90 cu. m)

Dry Bulk: 10,500 cu. ft. @ 80 psi (297.33 cu. m @ 5.5 bars)

Liquid Mud: 10,509 barrels (1670.8 cu. m)



Main Engines: Two (2) CAT 3606

Total Propulsion HP: 5,400 HP

Bow Thrusters: One (1) 1,200 HP Swing Up

Bow Thrusters: One (1) 1,000 HP Tunnel

Stern Thrusters: One (1) 1,000 HP Tunnel

Speed: 14.2 knots

Generators: Two (2) x 910 kW

Generators: One (1) x 170 kW emergency



Tuggers: Two (2) x 4 Tons

Ship Motion: Two (2) Passive Type Anti-Roll Tanks

Ship Motion: Bilge Keels

Positioning: DP 2

Deck Crane: One (1) x 3,100 lbs. capacity



Life Rafts: Four (4) x 25-Man Inflatable Life Rafts

Life Rafts: Two (2) x 10-Man Inflatable Lift Rafts

Rescue Boat/Craft: One (1) x Norsafe 6-Man Rescue Boat

Other gear as required by authorities



Electronics Package: Two (2) Pelco Video Cameras, Two (2) Furuno PP-510 Printers, Inmarsat-C Furuno Felcom 18, DSC Watch Receiver Furuno DSC-60, Furuno SSB (Single Sideband Radio), Kongsberg Simrad SDP-21 DP System, EPIRB RLB-32 ACR Electronics, Two (2) Furuno VHF FM 8900S, Navtex Receiver Furuno NX-300, Two (2) Furuno FR-2115-B (ARPA Capable) Radar, Two (2) Gyro Compasses, VSAT System, CyScan, Two (2) MRU, Two (2) Wind Trackers



ABS: Maltese Cross A1 (Hull)

ABS: Maltese Cross AMS (Machinery)

ABS: Loadline

ABS: DP 2

USCG: Subchapter L (OSV)

SOLAS

MARPOL



Accommodations: 29
