  1. Seaboats Main
  2. Commercial Vessels
  3. Offshore Industries
  4. Supply / Support Vessels

260ft Anchor Handling Vessel


Listing ID - 2182


Description260ft Anchor Handling Vessel
Date Launched
1998
Length79.25m (260ft)
Beam17.68m (58ft)
BrokerJohn Kearns
john.kearns@seaboatsbrokers.com
+64 21 400 805
View As PDF


REGISTRATION
Hull: 163
Vessel Type: Anchor Handling Supply Vessel
Year Built: 1998
Shipyard: North American Shipbuilding

DIMENSIONS
Dimensions: 260 ft. X 58 ft. X 24 ft. (79.25 m X 17.68 m X 7.32 m)
Draft (Normal Operation): 17 ft. (5.18 m)
Draft (Minimum Operation): 13 ft. (3.96 m)
Draft (Loadline): 20 ft. 2 in. (6.15 m)
Clear Deck: 136 ft. 3 in. x 48 ft. (41.53 m x 14.63 m)
Cargo Deck Area: 6,540 sq. ft. (607.59 sq. m)
Deck Cargo Capacity: 1,175 LT @ 3 ft. VCG (1,193.86 MT @ 0.91 m VCG)
Deadweight (Loadline Draft): 3,056 LT (3,105.04 MT)

CAPACITIES
Fuel Oil: 367,442 gals. (1.390.92 cu. m)
Ballast: 330,139 gals. (1,249.71 cu. m)
Potable Water: 32,576 gals. (123.31 cu. m)
Dry Bulk: 11,250 cu. ft. @ 80 psi (318.57 cu. m @ 5.5 bars)
Liquid Mud (Dual Tank System): 4,320 barrels (686.83 cu. m)

MACHINERY
Main Engines: Two (2) 3612 CAT Diesels, 11,400 BHP
Propulsion: Two (2) x 3,400 mm dia. C.P. in nozzels
Bow Thrusters: One (1) Ulstein 850 HP Tunnel
Bow Thrusters: One (1) Ulstein 1,200 HP Drop-Down Azimuthing
Stern Thrusters: One (1) Ulstein 1,200 HP Drop-Down Azimuthing
Bollard Pull: 120 MT at max draft
Speed: 14 knots
Rudders: Two (2) Spade Type, Independent Operation
Generators: Three (3) x 500 kW
Generators: One (1) 300 kW Emergency

TOWING AND ANCHOR HANDLING (DECK EQUIPMENT)
Winches: Brattvaag double drum SL500 Waterfall, 500 MT or 1,102,500 lbs. or 1,102 KIPS per drum
Chain Lockers: Two (2) x 5,425 ft. x 3-1/4 in. (1,653.54 m x 0.99 m) ea.
Storage Reels: Two (2) x 6,500 ft. of 3-3/4 in. (1,981.2 m of 1.14 m) wire ea.
Wire Capacity: Two (2) x 6,500 ft. of 3-3/4 in. (1,981.2 m of 1.14 m) wire @ 500 MT

SPECIAL FEATURES
Shark Jaws: Two (2) Sets Triplex 350 T (317.52 MT)
Synthetic Rope Shark Jaes: One (1) x 175 tons (158.76 MT)
Tow Pins: Two (2) Sets 300 T (272.16 MT)
Tuggers: Two (2) x 15 tons (13.61 MT)
Tuggers: Two (2) x 7.5 tons (6.8 MT)
Ship Motion: Two (2) Passive Type Anti-Roll Tanks
Ship Motion: Bilge Keels
Positioning: DP 2
Stern Rollers: One (1) 9 ft. (2.74 m) dia
Cranes: Two (2) x 5-ton Capacity
VSAT Domes: Internet and Television Dome
Oil Dispersant System: Two (2) Oily Water Separators
Sewage Treatment System
Thru Hull ROV Transducer Pole

ROV
ROV Deck

LIFE SAVING EQUIPMENT
Life Rafts: Six (6) x 20-Man Inflatable Life Rafts
Life Rings: 8 x Life Rings
Rescue Boat/Craft: One (1) x Fast RSQ-450
Other gear as required by authorities

ELECTRONICS
Electronics Package: Two (2) Furuno FAR 2xx7 Radars, Furuno GP-150, Glonass and C-Nav 3050, Standard Horizon VHF/FM Radio, Two (2) Seacall 7156 VHF/FM Radios, Two (2) Seacall 7100 VHF DSC Controllers, Sea 330 HF/SSB Radio, Seacall 7000 MF/HF DSC Controllers, Seawatch 7001 MF/HF Watch Receiver, Sailor R501 Watch Receiver, Necode LPWDSC 1000 DSC Encoder, JRC JUE-75C Inmarsat-C, Three (3) ICOM IC GM1600 VHF Survival Radio, Three (3) Jobcom JMX 444 Handheld FM Radios, Seatel Wavecall 2100R Satellite Telephone, ACR Satellite 406 EPIRB, JRC NCR-300A Navtex Receiver, Furuno F700, Standard Horizon HX2508 VHF Handheld Radio, Apple Power Mac 7600/132 Ship’s Computer, Anschutz Standard 20 Digital Gyrocompass, Three (3) Anschutz BSH/46/33G/94 Compass Repeaters, Two (2) Raytheon-Anschutz Compass Stand Repeaters, Marine Technologies Dynamic Positioning System (DP 2)

CLASSIFICATION
ABS: Star A-1 Unrestricted Ocean Services
ABS: Star AMS
ABS: Circle E
ABS: DP 2
USCG: Subchapter L (Industrial Vessel)
OPA: 1990
SOLAS: 1993
MARPOL: 1973/1978/1992

ACCOMMODATIONS
Accommodations: 39

2182: 260ft Anchor Handling Vessel - 095 Casey.jpg


The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
