Hull: 1324

Type: Fast Supply

Shipyard: Breaux Brothers Enterprises



Dimensions:190 ft. x 30 ft. x 14 ft. (59.13m x 9.14 m x 4.27 m)

Clear Deck: 132 ft. x 24ft. 6 in. (40.23m x 7.62m)

Clear Deck Area: 3, 234 sq. ft. (40.23m x 7.62m)

Deck Cargo Capacity: 380 LT (386.10 MT)

Deadweight Tonnage: 450 LT (457.22 MT)



Fuel Oil: 34, 000 gals. (128.7 m3)

Ballast: 62, 000 gals. (234.7 m3)

Potable Water: 900 gals. (3.41 m3)

Lube Oil: 350 gal. (1.32 m3)



Main Engines: Four (4) 3512C-HD CAT Diesels, 7, 240 BHP

Auxiliary Engine: One (1) CAT C9, 503 BHP

Bow Thrusters: Two (2) 200 HPThrustmaster 3077200 AL tunnels

Speed: 28 knots

Generators: Two (2) x 80 kW



Positioning: DP 2

Steering and Controls: Four (4) IMS 5 HP Electro / Hydraulic

Steering and Controls: Steering units, three (3) stations

Firefighting: 2 monitors @ 6, 000 GPM each



Life Rafts: Four (4) x 25-Man inflatable life rafts

Personal rescue davit

Other gear as required by authorities



Electronics Package: Two (2) Furuno FAR-2117 Radars, Furuno GP150D DGPS Navigator, Furuno FA150 AIS Transponder, Furuno FM-8800S VHF Radiotelephone, SEA 235 SSB Radio, Icom IC-M504 VHF Radio, Depth Recorder, Furuno NX700P Navtex Receiver, Color Video Sounder, RLB-32 EPIRB, Furuno LH3000 Loud Hailer, Two (2) Furuno GC10 Gyro Converters, Marine Technologies DP 2 Integrated Vessel Control System



ABS: A1 class

ABS: Loadline

ABS: AMS (HSC Crewboat)

ABS: DP-2

ABS: FiFi

USCG



Accommodations: 12

Passengers: 53
