170ft Fast Supply Vessel, built 2008.

Listing ID - 1001
Description	170ft Fast Supply Vessel
Date Launched	2008
Length	51.8 m (170ft)
Beam	9.14m (30ft)
Broker	John Kearns john.kearns@seaboatsbrokers.com +64 21 400 805
View As PDF

REGISTRATION

Hull: 49

Vessel Type: Fast Supply Vessel

Year Built: 2008

Shipyard: Breaux Brothers Enterprises

DIMENSIONS

Dimensions: 170 ft. X 30 ft. X 13 ft. 8 in. (51.8 m X 9.14 m X 4.17 m)

Clear Deck: 106 ft. (32.3 m)

Cargo Deck Area: 3920 sq. ft. (364.18 sq. m)

Deck Cargo Capacity: 285 LT (289.57 MT)

Deadweight Tonnage: 294 LT (298.72 MT)

CAPACITIES

Fuel Oil: 18,550 gals. (70.22 cu. m)

Ballast: 29,800 gals. (112.81 cu. m)

Potable Water: 900 gals. (3.41 m³)

Lube Oil: 350 gals. (1.32 m³)

Waste Oil/Bilge Oil: 350 gals. (1.32 m³)

MACHINERY

Main Engines: Four (4) 3512B CAT Diesels, 7,240 BHP

Auxiliary Engine: One (1) CAT C9

Bow Thrusters: Two (2) 200 HP Thrustmaster Tunnels

Speed: 28.5 knots

Generators: Two (2) x 80 kW

SPECIAL FEATURES

Positioning: DP 2

Steering and Controls: EMI Independent Rudder System

Steering and Controls: Dual Stations

Firefighting: One (1) Monitor @ 2,500 GPM

LIFE SAVING EQUIPMENT

Personnel Rescue Davit

Other gear as required by authorities

ELECTRONICS

Electronics Package: Two (2) Radars, Three (3) VHF Radios, One (1) SSB Radio, One (1) Depth Recorder, One (1) Navtex Receiver, One (1) WF/NT Plotter, One (1) Color Video Sounder, One (1) GPS, One (1) EPIRB, One (1) Loud Hailer, Marine Technologies DP 2 Integrated Vessel Control System, GMDSS

CLASSIFICATION

ABS: Loadline

ABS: A1 Class

ABS: AMS (HSC Crewboat)

ABS: DP2

ACCOMMODATIONS

Accommodations: 10

Passengers: 76

2244: 170ft Fast Supply Vessel, built 2008 - 095.jpg

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
