10.67m Single Screw Tug For Sale & Charter

Listing ID - 4448
Description	10.67m Single Screw Tug For Sale & Charter
Date Launched	2016
Length	10.67m (35ft)
Beam	4.52m (14ft 9in)
Draft	1.60m (5ft 2in)
Note	1x Volvo Penta
Location	The Netherlands
Price	EUR 725,000
View As PDF

Built: 2016, The Netherlands

Hull material: Steel

Flag: The Netherlands

Class Society and Notation: BV Sea Going Launch

PRINCIPLE DIMENSIONS

Length Overall: 10.67m

Breadth: 4.52m

Depth: 2.15m

Draft: 1.60m

MACHINERY & PROPULSION

Total power output: 296 bhp

Main Engine: 1 x Volvo Penta D9 MH/1

Main Propulsion System SINGLE SCREW

Speed cruising 8.7 knots

ADDITIONAL INFORMATION

Damen Stan Tug 1004

Reported to be like new

Engine 1600 running hours

Displacement: 29 Ton

Bollard Pull: 4.2 Ton(M)

Gearboxes/Ratio: Twin Disc Mg 5091 / 4.50:1

Propeller: Kaplan Fixed Pitch, 1050 Mm Diam.

Nozzle Van De Giessen ‘Optima’ With Stainless Steel Inner Side

Engine Control Volvo Eva

Rudder Double Plate High Performance

Steering Gear

Powered-hydraulic 2x 50º + rudder indicator

Tank Capacities

Fuel Oil: 1.62 m3

Fresh Water: 0.21m3

Sewage: 0.25 m3

Auxiliary Equipment

Battery Sets: 2x 24 V 230 Ah, change over facility

Alternators: 2x 80 Ah main engine driven

Alarm System: Engines, gearboxes + bilge alarm

Bilge/Fire Fighting System: Electrical driven Azcue CA50/2A 9 m3/h with connection to hydrants in engine room and on deck hand operated emergency bilge pump

Fuel Oil System: Water separators, filters + SOS valve

Cooling System: Closed cooling system (cooling channels)

Sanitary/Fresh Water System: Speck 24V pressure set, Rheinstrom 24V sewage discharge pump

Fire Extinguishers: 2x 5 kg CO2 and 2x 6 kg dry powder

Deck Lay-Out

Anchor: 48 kg Pool (High Holding Power)

Anchor Winch: Electrically driven 24V

Towing Hook: Mampaey Disc type, 7.1 ton SWL

Side/Stern Fender: Rubber D-fender 125 x125 mm

Push Bow: Cylindrical rubber fender Ø 380 mm

Towing Winches: 2x Dyvler 12 tons, with Dyneema wires.

Accommodation
The wheelhouse is resiliently mounted to reduce noise levels. The wheelhouse and below deck accommodation are completely insulated and finished with durable modern linings and composite/synthetic floor. Wheelhouse with a settee for two persons, a table, wash basin and a helmsman seat. Windows are fitted in aluminium frames. The store below deck is equipped with a toilet.

Nautical and Communication Equipment
Search Light: Den Haan 250 W 24V
Radar: Furuno Navnet Tz3 – 16 inch
Fluxgate Compass Radio Zeeland, Sigma 345
GPS Furuno GP-32
Echo Sounder: Furuno LS 6100
VHF Radio Telephone Sailor Compact 6248, 25 W
AIS Samyung SI-30
Navigation Lights: Navigation lights incl. towing light
Flood light: 150 Watt on aft deck

The details of all vessels are offered in good faith but we cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. Any buyer should instruct their agents, or their surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to sale, price change, location or withdrawal without notice.
